HALTIAN Fill Level Distance Sensor Laser Measurement 40mm to 4000mm Range

Finding the exact amount of material left in a tank or bin can be hard. When you guess, you may run out of product or over-fill and waste space. Both situations cost time and money. The Fill Level Distance Sensor Laser Measurement 40mm to 4000mm Range gives you a fast, accurate reading so you always know how much is left.

HALTIAN Fill Level Distance Sensor Laser Measurement 40mm to 4000mm Range with Fill

Never guess your tank level again. This sensor uses a safe Class 1 laser to measure distance from 40 mm up to 4 m. It sends the data to a cloud dashboard where you can see real-time fill information. If the level changes, the sensor alerts you instantly. It solves the common problem of manual checks that are slow and often inaccurate.

Usages

You can mount the sensor on water storage tanks to avoid running dry. It works well on grain silos where a quick check saves a whole harvest. Chemical plants use it to monitor drums and prevent spills. Waste-management teams place it on dumpsters to plan collection routes. Any place that needs a reliable fill reading can benefit.

Benefits

• Accurate readings reduce waste and prevent stock-outs.
• Remote alerts keep you informed without climbing ladders.
• Long battery life means years of operation without change.
• Easy cloud configuration lets you set reporting intervals.
• Safe laser class protects workers and the environment.

Key Features

• Measurement range 40 mm - 4000 mm.
• 25 mm accuracy depending on surface reflectance.
• Adjustable field of view from 15 to 27.
• Two range modes: short (40 mm - 1300 mm) and long (up to 4000 mm).
• IP40 protection for indoor use.
• Battery: 2 AAA replaceable, up to 5 years on 15-minute interval.
• Bluetooth Low Energy radio sensitivity -95 dBm.
• Class 1 laser safe under all conditions.
• CE, FCC, ISED, RoHS, UKCA certified.
• Cloud-based remote configuration of intervals, thresholds, and ROI.
