Gemini 335L Stereo Smart Vision Camera 1280x800 Depth USB C

Imagine seeing the world in 3-D without any extra hassle. The Gemini 335L Stereo Smart Vision Camera gives you depth perception and clear color images in one compact device. If you have struggled with blurry depth data or slow video, this camera solves those issues so you can build smarter robots, better AR apps, or precise measurement tools.

Gemini 335L Stereo Smart Vision Camera 1280x800 Depth USB C

Many makers need accurate depth information but end up with noisy or low-resolution results. Poor depth data makes navigation unsafe and mapping unreliable, which can cost time and money. Gemini camera delivers high-resolution depth maps at up to 30 fps, a wide field of view, and reliable performance from 0.25 m to 6 m. The USB-C connection supplies power and data in one cable, so setup is quick and tidy.

Usages of Gemini

Robotics engineers use Gemini to help drones avoid obstacles and to map indoor spaces. AR developers add realistic depth to games and training simulations. Quality inspectors attach the camera to a conveyor line to measure product dimensions in real time. Researchers capture 3-D data for experiments in computer vision and machine learning.

Benefits

• Fast depth maps let you react in real time.
• High resolution RGB video improves visual detail.
• Low power use keeps battery life long.
• Simple USB-C plug reduces cable clutter.
• Compact size fits tight spaces and mounts easily.

Key Features

• Stereo depth technology with 850 nm wavelength.
• Depth range 0.17 m to over 20 m (optimal 0.25-6 m).
• Resolution up to 1280 800 at 30 fps for depth.
• RGB video up to 1280 800 at 60 fps.
• Horizontal FOV 90, vertical FOV 68 for RGB.
• Horizontal FOV 90, vertical FOV 65 for depth.
• Spatial precision 0.8 % at 2 m, 1.6 % at 4 m.
• Orbbec ASIC processing for low latency.
• USB 3.0 Type-C for data and power, under 3 W consumption.
• Dimensions 124 mm 29 mm 27 mm, weight 133 g.
• Supports indoor and outdoor environments from -10 C to 50 C.
