Hikvision DS-2CD2146G2-ISU outdoor IP dome camera mounted on a white wall, showing wide-angle view for home or business security
Hikvision DS-2CD2146G2-ISU outdoor IP dome camera mounted on a white wall, showing wide-angle view for home or business security
Hikvision DS-2CD2146G2-ISU outdoor IP dome camera mounted on a white wall, showing wide-angle view for home or business security
Logo

Hikvision DS-2CD2146G2-ISU Outdoor IP Security Dome Camera Wired White

UK Free Shipping UK Free Shipping over £249


Buy 5 or More Units - Unlock Priority Discounts!
Buy 20 or More Units - Get Exclusive Volume Discounts!


Also Support: Google & Apple Pay

Are you a reseller or placing a large order?
We're happy to offer Special Pricing tailored to your needs.
Click "Request Quote" or email us at [email protected] to get your best price today!

Add to Wishlist

Compare

Product Code: CCEL-115

MPN #: 311314714

Worried that a blind spot could let trouble slip by? The Hikvision DS-2CD2146G2-ISU Outdoor IP Security Dome Camera Wired White gives you clear eyes on every corner, day or night. It is built for homes, businesses and any place that needs reliable video watch. If you have been frustrated by fuzzy images, missed motion alerts or a camera that cannot survive rain, this device is the answer.



Hikvision DS-2CD2146G2-ISU Outdoor IP Security Dome Camera Wired White

Many users struggle with cameras that trigger alarms for every passing leaf or animal, wasting time and storage. That problem matters because false alerts can hide real threats and raise security costs. This camera uses Hikvision AcuSense deep-learning to tell the difference between people, vehicles and background motion, so you only get the alerts that count. Its weather-proof housing, night vision up to 30 m and 4 MP resolution give you a clear picture no matter the conditions.



Usages of Hikvision

Install it on a storefront to watch customers and deter shoplifting. Mount it on a ceiling in a school hallway to capture clear images of anyone entering or leaving. Use it in a parking garage to recognize cars and alert you to unauthorized vehicles. Place it on a home porch to see who is at the door, even in total darkness. The flexible wall or ceiling mount lets you fit it wherever you need coverage.



Benefits
    • Reduces false alarms by focusing only on human and vehicle movement.
    • Provides clear color video day and night, so you never miss detail.
    • IP67 rating protects the camera from rain, dust and extreme temperatures.
    • Easy PoE wiring means quick installation with a single cable.
    • Built-in microphone captures audio for added evidence.



Key Features
    • 4 MP CMOS sensor with 2688 1520 maximum resolution.
    • 98 diagonal lens gives a wide field of view.
    • 30 m infrared night vision for clear black-and-white images.
    • Wide Dynamic Range (WDR) balances bright and dark areas.
    • H.265+ compression saves bandwidth and storage.
    • MicroSD slot supports up to 256 GB for local recording.
    • Power over Ethernet (PoE) consumes only 6.5 W.
    • IK10 vandal-proof housing and metal construction.
    • Built-in alarm I/O for integration with other security devices.
    • Remote access via web browser and mobile app.



Specifications
Performance
Number of languages 33
Alarm input/output Yes
Day/night mode Yes
Wide Dynamic Range (WDR) Yes
Connectivity technology Wired
Placement supported Outdoor
Type IP security camera
Design
IK code IK10
International Protection (IP) code IP67
Housing material Metal
Product colour White
Mounting type Ceiling/wall
Form factor Dome
Camera
Camera shutter speed 1/3 - 1/100000 s
Pan range 0 - 355°
Tilt angle range 0 - 75°
Lens viewing angle, diagonal 98°
Lens viewing angle, vertical 45°
Lens viewing angle, horizontal 83°
Angle of rotation 355°
Minimum illumination 0 lx
Camera tilt control Yes
Camera pan control Yes
Image sensor
Progressive scan Yes
Optical sensor size 25.4 / 3 mm (1 / 3")
Number of sensors 1
Sensor type CMOS
Lens system
Detect distance (wide) 80 m
Fixed focal length 4 mm
Identify distance (wide) 8 m
Observe distance (wide) 31.7 m
Recognize distance (wide) 16 m
Maximum aperture number 1.4
Number of lenses 1
Night vision
Infra-red wavelength 850 nm
LED type IR
Night vision distance 30 m
Night vision Yes
Video
Back Light Compensation (BLC) Yes
Bit rate 32 Kbps - 8 Mbps
Bit rate control Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Highlight Compensation (HLC) Yes
Image quality adjustment Brightness, Contrast, Saturation, Sharpness
Privacy masking Yes
Region of Interest (ROI) encoding Yes
Noise reduction technology 3D noise reduction
Noise reduction Yes
Video streaming Yes
Frame rate 30 fps
Supported graphics resolutions 640 x 360, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2688 x 1520
Video compression formats H.264, H.264+, H.265, H.265+, M-JPEG
Total megapixels 4 MP
Maximum resolution 2688 x 1520 pixels
Audio
Voice codecs AAC, G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, PCM
Built-in microphone Yes
Sample rate 48 kHz
Audio formats supported MP3
Network
Quality of Service (QoS) support Yes
Number of users 32 user(s)
Supported network protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP
Networking standards IEEE 802.1x, IEEE 802.3af
Ethernet interface type Fast Ethernet
Bluetooth No
Wi-Fi No
Ethernet LAN Yes
Storage
Maximum memory card size 256 GB
Compatible memory cards MicroSD (TransFlash), MicroSDHC, MicroSDXC
Card reader integrated Yes
Built-in HDD No
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
Security
Anti-flicker Yes
Heartbeat Yes
Intelligent Video Surveillance (IVS) system features Scene change
Mirror Yes
Video motion detection Yes
Management features
Behavior analysis Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
Reset button Yes
Web-based management Yes
Power
DC output current 0.4 A
DC output voltage 12
Power consumption (Power over Ethernet (PoE)) 6.5 W
Power consumption (max) 5 W
Power source type DC, PoE
Operational conditions
Storage relative humidity (H-H) 0 - 95%
Operating relative humidity (H-H) 0 - 95%
Storage temperature (T-T) -30 - 60 °C
Operating temperature (T-T) -30 - 60 °C
Weight & dimensions
Weight 580 g
Diameter 12.1 cm
Height 92.2 mm
Packaging data
Package weight 820 g
Package height 141 mm
Package depth 150 mm
Package width 150 mm
Supplier features
Manufacturer Hikvision
Packaging content
Number of cameras 1
Other features
Maximum resolution 2688 x 1520 pixels
