Milesight IoT Controller LoRaWAN UC300-915M Interface Industrial Control Unit

Imagine a factory floor where every sensor talks instantly, and you can change a valve from miles away. The IoT Controller LoRaWAN UC300-915M Multi Interface Industrial Control Unit makes that possible. It is a compact controller that connects sensors, relays, and meters to a LoRaWAN network. If you struggle with wired cabling, signal loss, or slow data, this unit gives you a reliable wireless bridge that keeps your operations running smoothly.

Milesight IoT Controller LoRaWAN UC300-915M Multi Interface Industrial Control Unit

Many plants face the problem of outdated wiring that cannot keep up with modern data needs. The lack of real-time information leads to downtime and higher maintenance costs. This controller solves the issue by offering LoRaWAN and Milesight D2D wireless protocols, so you get long-range, low-power communication without digging trenches. It matters because faster alerts and remote control protect equipment and improve productivity. The UC300-915M delivers a clear solution: plug-and-play digital, analog, and serial interfaces that speak directly to your cloud or local server.

Usages of IoT

The unit fits any setting that needs reliable remote monitoring. Use it in water treatment plants to read flow meters and trigger pumps. Deploy it in agricultural fields to collect soil moisture data and control irrigation valves. Install it on production lines to monitor temperature, pressure, and motor status, then send alerts to a mobile app. It also works in smart buildings for lighting control and energy usage tracking. Each scenario benefits from the same easy wiring and long-range wireless link.

Benefits

• Remote control saves travel time and reduces labor costs.
• Instant alerts prevent equipment failure and lower downtime.
• Low power consumption extends battery life for field installations.
• Multi-interface design lets you connect many sensor types with one device.
• IP30 housing protects the unit in dusty industrial environments.

Key Features

• LoRaWAN and Milesight D2D protocols for secure long-range links.
• Supports CN470, IN865, EU868, RU864, US915, AU915, KR920, AS923 bands.
• 16 dBm (868 MHz) / 20 dBm (915 MHz) transmit power for strong signal.
• Four opto-isolated digital inputs (3-24 VDC) with pulse-counter mode.
• Two SPDT relay outputs rated up to 3 A @ 30 VDC or 250 VAC.
• RS232 and RS485 ports with Modbus RTU support for legacy equipment.
• Two 4-20 mA and two 0-10 V analog inputs with 12-bit resolution.
• Two PT100 RTD inputs (2- or 3-wire) covering -200 C to 800 C.
• Power options: 5-24 VDC terminal block or 5 V USB-C for flexible installation.
• Operating temperature -20 C to 60 C and humidity up to 95 % non-condensing.
• Compact size 93 70 22 mm, weight 186 g, mountable on desktop, wall, or DIN rail.
• Easy configuration via a single USB-C connection.
