Easy to manage, fundamental network features at an affordable cost for SMBs. GS305EP offers 63W total power budget to power devices PoE devices such as VoIP phones, IP cameras, wireless access points, etc.
New and improved Smart Managed Plus switches
Along with the already great Smart Managed Plus features, GS305EP enhances your business networking experience even more with exciting new features: advanced PoE controls with uninterrupted PoE and more, business-friendly GUI, simplified VLAN and QoS set-up, and multi-language support.
Why GS305EP?
- Cost-effective business networking management features: VLAN, QoS, advanced PoE controls, etc.
- Data security and network separation to safeguard your business.
- Advanced per port PoE controls (including power allocation override) and remote enable/disable/power cycle.
- Smart Managed Plus switch that now provides PoE+ to power devices such as wireless APs, IP cameras, VoIP phones, access-controlled security door locks or any other IoT PoE-powered devices.
Why 300 Series NETGEAR Smart Managed Plus?
- NETGEAR has the largest PoE switch portfolio in the market.
- Provides both basic and advanced management features at a cost-effective price for SMBs.
- Uninterrupted PoE and PoE controls in a Smart Plus switch.
- Reliability of the NETGEAR switches.
Specifications
| Management features |
| Web-based management |
Yes |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L3 |
| Switch type |
Managed |
| Ports & interfaces |
| Installed SFP+ modules quantity |
0 |
| Installed SFP modules quantity |
0 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
5 |
| Network |
| Number of VLANs |
64 |
| VLAN support |
Yes |
| Link aggregation |
Yes |
| Rate limiting |
Yes |
| Port mirroring |
Yes |
| 10G support |
No |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Data transmission |
| Packet buffer memory |
0.192 MB |
| Jumbo frames |
9216 |
| Store-and-forward |
Yes |
| Switching capacity |
10 Gbit/s |
| MAC address table |
4000 entries |
| Security |
| Loop protection |
Yes |
| Password protection |
Yes |
| Queue scheduling algorithms |
Weighted Round Robin (WRR) |
| IGMP snooping |
Yes |
| DHCP features |
DHCP client |
| Multicast features |
| Multicast support |
Yes |
| Design |
| Wall mountable |
Yes |
| LED indicators |
Activity, Link, PoE, Power, Speed, System |
| Housing material |
Metal |
| Product colour |
Black |
| Rack mounting |
No |
| Performance |
| Mean time between failures (MTBF) |
1164104 h |
| Fanless |
Yes |
| Power |
| Input current |
1.25 A |
| Power supply included |
Yes |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
63 W |
| Power over Ethernet plus (PoE+) ports quantity |
4 |
| Power over Ethernet (PoE) ports quantity |
4 |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Non-operating altitude |
0 - 3000 m |
| Operating altitude |
0 - 3000 m |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating relative humidity (H-H) |
0 - 90% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Weight & dimensions |
| Weight |
390 g |
| Height |
27 mm |
| Depth |
101 mm |
| Width |
158 mm |
| Packaging content |
| Quick start guide |
Yes |
| Certificates |
| Certification |
CE mark, commercial, FCC Part 15 class B, CE/EN55032/24, VCCI, ACMA, CSA safety, KC, BSMI |
