NETGEAR SOHO Ethernet Unmanaged Switches
SOHO Ethernet Unmanaged Switches provide easy and affordable network connectivity to small offices and home offices. They are easy to use, reliable, and rugged with metal enclosures. Power-over-Ethernet (PoE) support is also available for supplying both power and data across a single CAT-5 ethernet cable to devices such as IP security cameras, VoIP phones, wireless access points, and more. With these Plug and Play switches, you can quickly and easily expand your network connections to multiple devices, with no configuration required. Available with 5 to 48 ports, these switches also support energy saving technologies to help you save your power and money.
Extended Features
- Choice of Fast Ethernet and Gigabit Ethernet connectivity
- Energy-efficient technology for power savings
- Auto-MDI/MDIX eliminates the need for crossover cables
- Non-blocking switching architecture for maximum throughput at wire speed
- Auto-negotiation for automatic connection at the highest common speed between switch and an end device
- Power-over-Ethernet (PoE) option available for powering IP Security Cameras, VoIP phones, wireless access points, and other PD-powered devices
- Fanless design for silent opeartion
- Desktop, wall-mountable or rack-mountable (GS324, GS348)
Specifications
| Management features |
| Quality of Service (QoS) support |
Yes |
| Switch type |
Unmanaged |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
48 |
| Network |
| Auto MDI/MDI-X |
Yes |
| Auto-negotiation |
Yes |
| Auto-sensing |
Yes |
| Cable length detection |
Yes |
| Full duplex |
Yes |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| 10G support |
No |
| Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u |
| Data transmission |
| Packet buffer memory |
1.5 MB |
| Packet forwarding rate (1 Gbps) |
1448000 pps |
| Jumbo frames |
12288 |
| Jumbo frames support |
Yes |
| Latency (1 Gbps) |
4 µs |
| Forwarding rate |
1.448 Mpps |
| Switching capacity |
96 Gbit/s |
| MAC address table |
8000 entries |
| Security |
| Queue scheduling algorithms |
Weighted Round Robin (WRR) |
| Design |
| Number of fans |
2 fan(s) |
| LED indicators |
Activity, Link, PoE, Power, Speed |
| Housing material |
Metal |
| Product colour |
Black |
| Rack mounting |
Yes |
| Performance |
| Mean time between failures (MTBF) |
570972 h |
| Power |
| Power consumption (max) |
410 W |
| AC input frequency |
50 - 60 Hz |
| AC input voltage |
110 - 240 V |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
380 W |
| Power over Ethernet (PoE) power per port |
30 W |
| Power over Ethernet (PoE) ports quantity |
24 |
| Power over Ethernet (PoE) |
Yes |
| Operational conditions |
| Heat dissipation |
1402.2 BTU/h |
| Operating temperature (T-T) |
0 - 45 °C |
| Operating altitude |
0 - 3000 m |
| Storage relative humidity (H-H) |
10 - 95% |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating temperature (T-T) |
0 - 45 °C |
| Weight & dimensions |
| Weight |
4.56 kg |
| Height |
43 mm |
| Depth |
310 mm |
| Width |
440 mm |
| Packaging content |
| Rack mount kit |
Yes |
| User guide |
Yes |
| Cables included |
AC |
| Certificates |
| Certification |
CE, FCC 15 A, IC A, RCM, VCCI, KC CB, CE LVD, UL |
