Running a small office or a busy home network can leave you with slow, dropped connections. When many devices share the same Wi-Fi, you lose productivity and get frustrated. The NETGEAR Insight WiFi 6 AX1800 Dual Band Access Point, 2.4 GHz, 5GHz, 1800 Mbit/s gives you fast, reliable wireless that handles many users at once. It removes dead spots and keeps your work and entertainment smooth.
NETGEAR Insight WiFi 6 AX1800 Dual Band Access Point, 2.4 GHz, 5GHz, 1800 Mbit/s with NETGEAR
You need a network that can keep up with video calls, cloud apps, and streaming in the same space. This device is a professional-grade access point that brings Wi-Fi 6 speed to both 2.4 GHz and 5 GHz bands. It supports up to 250 users, so your team or family can work and play without lag. With built-in VLAN support and advanced security, NETGEAR makes it easy to protect data while delivering 1800 Mbit/s total throughput.
Usages
Install the access point on a ceiling or wall in a conference room to give every seat strong signal. Use it in a retail store to support point-of-sale tablets and guest Wi-Fi at the same time. It works well in a co-working space where many laptops and phones need fast, secure connections. The PoE option lets you power it from a switch, reducing cable clutter.
Benefits
- Fast Wi-Fi 6 speeds keep video calls clear and downloads quick.
- Supports up to 250 users, so growth never slows your network.
- Built-in security features protect business data and guest traffic.
- PoE power simplifies installation and reduces extra wiring.
Specifications
| Features |
| VLAN support |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Spread spectrum method |
OFDM, OFDMA |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Auto MDI/MDI-X |
Yes |
| Number of users |
250 user(s) |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Maximum data transfer rate (5 GHz) |
1200 Mbit/s |
| Maximum data transfer rate (2.4 GHz) |
600 Mbit/s |
| Maximum data transfer rate |
1800 Mbit/s |
| 5 GHz |
Yes |
| 2.4 GHz |
Yes |
| Security |
| Remote Authentication Dial-In User Service (RADIUS) |
Yes |
| Auto Wireless Distribution System (WDS) |
Yes |
| Number of SSID supported |
8 |
| Service Set Identifier (SSID) features |
Multiple SSIDs, SSID broadcast, SSID broadcast on/off |
| MAC address filtering |
Yes |
| Security algorithms |
EAP-PEAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, WPA, WPA2, WPA2-Enterprise, WPA3 |
| Ports & interfaces |
| DC-in jack |
Yes |
| USB 2.0 ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
| Input current |
2.5 A |
| AC input voltage |
12 V |
| Power over Ethernet (PoE) |
Yes |
| Design |
| LED indicators |
LAN, Power, Status |
| Reset button |
Yes |
| Product colour |
White |
| Placement |
Ceiling, Wall |
| Antenna |
| Antenna gain level (max) |
4.5 dBi |
| Antenna type |
Internal |
| Weight & dimensions |
| Weight |
412 g |
| Height |
33.2 mm |
| Depth |
160.9 mm |
| Width |
160.9 mm |
| Packaging data |
| Package weight |
3.98 kg |
| Package height |
235 mm |
| Package depth |
455 mm |
| Package width |
220 mm |
| Packaging content |
| Mounting kit |
Yes |
| Quantity per pack |
1 pc(s) |
| Other features |
| Operating temperature (T-T) |
0 - 40 °C |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
