Milesight Outdoor LoRaWAN Gateway UG67 4G LTE IP67 8 Channel IoT Gateway

Tired of losing sensor data because your gateway cant survive the weather? The Outdoor LoRaWAN Gateway UG67 4G LTE IP67 8 Channel IoT Gateway is built for harsh environments and gives you reliable connectivity for every IoT device. Farmers, city planners, and utility crews all face the same problem - a gateway that stops working when rain, dust, or extreme temperature hits. You need a device that stays online, talks to many sensors, and works even where power and network are limited.

Milesight Outdoor LoRaWAN Gateway UG67 4G LTE IP67 8 Channel IoT Gateway

When a gateway fails, data stops, decisions stall, and costs rise. This matters because every missing data point can mean a missed alert, a wasted resource, or a delayed response. The UG67 solves the issue with a rugged IP67 case, built-in 4G LTE backup, and eight LoRaWAN channels that handle thousands of devices at once. It gives you a clear, always-on link between your sensors and the cloud, no matter where you install it.

Usages of Outdoor

Use the gateway on a farm to collect soil moisture, temperature, and livestock tracker data across many acres. Install it on a city street pole to manage smart lighting, air-quality monitors, and parking sensors. Place it at a remote water treatment plant to monitor pump status, flow meters, and leak detectors. It also works for wildlife conservation projects that need GPS collars and environmental sensors in rugged terrain.

Benefits

• Stay online in rain, dust, and extreme temperatures.
• Connect up to 2000 LoRa devices on eight channels.
• Automatic 4G LTE failover keeps data moving when Ethernet drops.
• Easy wall or pole mounting saves installation time.
• Low power use (3.6 W typical) reduces electricity cost.

Key Features

• Quad-core 1.5 GHz ARM Cortex-A53 CPU.
• 512 MB DDR4 RAM and 8 GB eMMC storage.
• Eight half/full-duplex LoRa channels (CN470/IN865/EU868/US915 etc.).
• -140 dBm sensitivity for long-range reception.
• 27 dBm max transmit power for strong uplink.
• IP67 sealed enclosure with PC-plus-aluminum housing.
• PoE support and 6-12 VDC power options.
• RJ45 WAN port with auto-sensing 10/100/1000 Mbps.
• Built-in Wi-Fi (AP or client) with internal antenna.
• 4G LTE mini-SIM slot for cellular backup.
• GPS/GLONASS/QZSS/SBAS for precise location.
• Full firewall, VPN (OpenVPN, WireGuard, etc.) and WAN failover.
