Siemens IOT2050 IoT gateway front view with dual Ethernet ports and compact design
Siemens IOT2050 IoT gateway front view with dual Ethernet ports and compact design

Siemens IOT2050 IoT Gateway 2GB RAM Dual Ethernet Industrial PC

UK Free Shipping UK Free Shipping over £249


Buy 5 or More Units - Unlock Priority Discounts!
Buy 20 or More Units - Get Exclusive Volume Discounts!


Also Support: Google & Apple Pay

Are you a reseller or placing a large order?
We're happy to offer Special Pricing tailored to your needs.
Click "Request Quote" or email us at [email protected] to get your best price today!

Add to Wishlist

Compare

Product Code: MNHO-228

MPN #: 6ES7647-0BA00-1YA2

Imagine your factory floor talking to the cloud without delays or crashes. The Siemens IOT2050 IoT Gateway 2GB RAM Dual Ethernet Industrial Controller is built for that exact need. It connects sensors, machines and control systems to modern IoT platforms. If you struggle with unreliable data links or lack a compact controller that can survive harsh conditions, this gateway gives you a stable, fast, and secure bridge.



Siemens IOT2050 IoT Gateway 2GB RAM Dual Ethernet Industrial PC

The main problem many engineers face is a controller that cannot handle both high-speed Ethernet traffic and the rugged environment of an industrial plant. When data packets are lost or the device overheats, production stops and costs rise. This Siemens gateway solves the issue by offering dual Ethernet ports, a powerful ARM processor, and 2 GB of DDR4 RAM, all inside a compact IP20 enclosure. It runs the SIMATIC Industrial OS, so you can deploy standard PLC programs and IoT services without rewriting code. The device also includes a 5 ms mains buffering circuit that protects against short power interruptions. Its LED status display lets you see health at a glance, and the built-in temperature monitoring warns you before overheating occurs

Specifications
Category Feature Specification
General Product type designation IOT2050
Mounting Design IoT Gateway, built-in unit
Supply Voltage Type of supply voltage 12/24 V DC
Mains Buffering Mains/voltage failure stored energy time 5 ms
Processor Processor type ARM TI AM6548 HS
Graphics Graphics controller Integrated
  Graphics card Yes
Drives Slot for drives 1x microSD card slot
Memory Type of memory DDR4
  Main memory 2 GB RAM
  Capacity of main memory, max. 2 Gbyte
Digital Inputs Number of digital inputs 20
  Type of input voltage DC
Digital Outputs Number of digital outputs 20
  Type of output voltage DC
  Permissible voltage at output, min. 3.3 V
  Permissible voltage at output, max. 5 V
Analog Inputs Number of analog inputs 6
  Input ranges (Voltage) Yes; 0 ... 5 V
Interfaces Industrial Ethernet interfaces 2
  PROFINET interfaces 2
  Serial interface 1x COM (1x RS 232 / 422 / 485)
  Graphics interface 1x DisplayPort
Industrial Ethernet 100 Mbps Yes
  1000 Mbps Yes
Diagnostics LED status display Yes
Monitoring Temperature monitoring Yes
Protection IP degree of protection IP20
  IP (all-round) IP20
Certificates CE mark / UL / cULus Yes
  RCM / KC / EAC / FCC Yes
Sustainability Environmental product declaration Yes
  Global warming potential (Total) 196 kg CO2 eq
  GWP (Production) 18.7 kg CO2 eq
  GWP (Operation) 179 kg CO2 eq
  GWP (End of life cycle) -2.28 kg CO2 eq
Operation Temp Min / Max 0 °C / 50 °C
Storage Temp Min / Max -20 °C / 70 °C
Environment Max altitude (sea level) 2 000 m
  Relative humidity (Max) 85 %
  Vibration resistance IEC 60068-2-6: 10 cycles; 5-8.4 Hz (3.5mm); 8.4-200 Hz (9.8 m/s²)
OS Pre-installed operating system SIMATIC Industrial OS
  Without operating system No
Material Enclosure material (front) Plastic
  Material components Plastic (Yes), Aluminum (Yes), Stainless steel (Yes), Glass (No)
Dimensions Width / Height / Depth 37 mm / 142 mm / 100 mm
