Many businesses need a network that never drops, even in harsh places like factories, farms, or moving vehicles. When the connection fails, work stops, data is lost and money is wasted. You also need a device that can handle 5G, LTE and older networks without a lot of extra hardware. The Teltonika RUTX50, 256 MB RAM Industrial 5G Sub-6GHz ROUTER gives you fast, reliable internet in one rugged box, so you can keep operations running smoothly.
Teltonika RUTX50, 256 MB RAM Industrial 5G Sub-6GHz ROUTER with Teltonika
Imagine a router that works in a freezer, a desert, or on a moving truck and still delivers 5G speeds. That is what the Teltonika RUTX50 does. It is an industrial-grade router built for demanding environments and for users who cannot afford downtime. If you struggle with weak signals, frequent reboots or complex wiring, this device solves those problems with a single, easy-to-manage solution. Teltonika brings the power of modern mobile networks to your site without the usual headaches.
Key Features
- 5G Sub-6GHz SA/NSA, up to 3.3 Gbps downlink.
- LTE Cat 20, 2 Gbps downlink, 200 Mbps uplink.
- Quad-core ARM Cortex-A7 CPU at 717 MHz.
- 256 MB RAM and 256 MB flash storage.
- Five Gigabit Ethernet ports (1 WAN/4 LAN).
- Two Mini-SIM slots for carrier redundancy.
- GNSS support: GPS, GLONASS, BeiDou, Galileo, QZSS.
- Wi-Fi mesh (802.11s) and fast roaming (802.11r).
- Aluminum housing with DIN-rail mounting and flat-surface option.
- Operating temperature from -40 C to 75 C.
- 4-pin power input, 9-50 VDC, plus digital I/O and USB host.
NOTE: This product is the EMEA / APAC VERSION with EU plug and is incompatible in USA & CANADA.
Specifications
| HARDWARE |
|
| Mobile |
5G Sub-6GHz SA/NSA 2.1/3.3Gbps DL (4x4 MIMO), 900/600 Mbps UL (2x2);
4G (LTE) – LTE Cat 20 2.0Gbps DL, 200Mbps UL; 3G – 42 Mbps DL, 5.76 Mbps UL
|
| CPU |
Quad-core ARM Cortex A7, 717 MHz |
| Flash storage |
256 MB |
| RAM |
256 MB |
| Powering options |
4-pin power socket, 9-50 VDC |
| SIM |
2 x SIM slot (Mini SIM – 2FF), 1.8 V/3 V |
| Antenna connectors |
4 x SMA for Mobile, 2 x RP-SMA for WiFi, 1 x SMA for GNSS |
| Ethernet |
5 x 10/100/1000 Ethernet ports: 1 x WAN (configurable as LAN), 4 x LAN |
| WiFi |
|
| GNSS |
GPS, GLONASS, BeiDou, Galileo, QZSS |
| Wireless mesh/roaming |
Wireless mesh (802.11s), fast roaming (802.11r) |
| Inputs/Outputs |
On 4-pin socket: 1 x Digital input, 1 x Digital open collector output |
| Other |
1 x USB host, 1 x Grounding screw |
| Status LEDs |
|
| Operating temperature |
-40 °C to 75 °C |
| Housing |
Aluminum housing, DIN rail (can be mounted on two sides), flat surface placement |
| Dimensions (W x H x D) |
132 x 44.2 x 95.1 mm |
| Weight |
533 g |
| SOFTWARE |
|
| 5G NR NSA |
n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78 |
| 5G NR SA |
n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78 |
| 4G (LTE-FDD) |
B1, B3, B5, B7, B8, B20, B28, B32 |
| 4G (LTE-TDD) |
B38, B40, B41, B42, B43 |
| 3G |
B1, B5, B8 |
