Advantech UNO-2473G Industrial Automation PC Intel Atom J1900 Fanless 4GB DDR3L

Factory floors are full of dust, heat and constant motion. A regular PC can overheat, fail, or need frequent service in that kind of place. When a controller stops, the whole line can pause and you lose time and money. The UNO-2473G Industrial Automation PC Intel Atom J1900 Fanless 4GB DDR3L removes the fan, adds a rugged aluminum case and runs cool 24/7, giving you a reliable computer that never slows down your production.

Advantech UNO-2473G Industrial Automation PC Intel Atom J1900 Fanless 4GB DDR3L with Industrial

Imagine a small box that can survive the toughest factory environment and keep your machines talking. This is an Industrial PC built for control panels, data logging and edge computing. It uses an Intel Atom J1900 quad-core processor, 4 GB DDR3L memory and a fan-free design, so there are no moving parts to break. If your production line needs a stable heart that never stops, this unit gives you exactly that, while fitting into tight spaces.

Usages

The computer works well in assembly line controllers, robotic cell interfaces and machine vision stations. It can be mounted in harsh outdoor kiosks for monitoring water treatment plants. It also fits into vending machines, traffic signal controllers and warehouse conveyor systems where dust and vibration are common. Any place that needs a small, reliable computer without a fan can use this device.

Benefits

• Runs cool without a fan, so dust and moving parts never cause failure.
• Compact size fits into tight panels and enclosures.
• 24 VDC power input matches common industrial power supplies.
• Multiple LAN and serial ports let you connect to PLCs, sensors and cameras.
• Supports Windows and Linux, giving you flexibility for any software.

Key Features

• Intel Celeron E3845 quad-core CPU at 1.91 GHz.
• Intel HD Graphics Gen7 with 4EU for clear display output.
• 4 GB DDR3L 1600 MHz memory, expandable via SO-DIMM.
• One mSATA slot and one 2.5 SSD/HDD bay for storage.
• Four Gigabit Ethernet ports for fast networking.
• USB 3.0 and three USB 2.0 ports for peripherals.
• Two RS-232 and two RS-422/485 serial ports for industrial devices.
• HDMI and VGA video outputs for dual-monitor setups.
• Aluminum housing that meets CE, FCC, UL, CCC and BSMI certifications.
• Dimensions 252 149 62 mm and weight 1.6 kg for easy mounting.

Specifications
