Near silent operation
The GS1900 Series includes both fan-less and built-in smart fan models. The smart fan is designed to automatically adjust speed based on device temperature. You can barely hear the sound while the switch is operating. It is ideal for your office environment.
Intelligent PoE+ powers more devices
PoE models (8HP/10HP/24EP/24HPv2/48HPv2) come with default PoE consumption mode which delivers only the actual power required by your networked devices, reserves the rest and optimizes its power budget. That means a single switch can power more APs, IP cameras and VoIP phones, ensuring a better ROI for your business. All of them support the IEEE 802.3at providing a maximum of 30W per port.
Speedy Gigabit performance-built for SMBs
The GS1900 is a series of switches with full non-blocking bandwidth of up to 1 Gbps per port. An ideal upgrade from an unmanaged switch, it’s a great choice for SMBs that want to enjoy high-speed business network applications at full wired non-blocking speed.
Easy and intuitive management
The Smart Managed GS1900 Series switch feature with web-based interface to manage advanced functions such as VLAN, QoS, IGMP Snooping, Link Aggregation (LAG), IPv6 and DoS prevention easily. Also, the user-friendly wizard helps to walk through setup, configuration and even advanced settings quickly.
Specifications
| Management features |
| MIB support |
RFC 1213 MIB II RFC 2819 RMON (group 1, 2, 3, 9) RFC 1215 generic traps RFC 1493 bridge Zyxel private common MIB |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L2 |
| Switch type |
Managed |
| Ports & interfaces |
| Power connector |
AC-in jack |
| Installed SFP+ modules quantity |
0 |
| Installed SFP modules quantity |
0 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| Network |
| Virtual LAN features |
Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN |
| VLAN support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Flow control support |
Yes |
| Link aggregation |
Yes |
| MAC address auto-learning supported |
Yes |
| Spanning tree protocol |
No |
| Full duplex |
Yes |
| Port mirroring |
Yes |
| Cable types supported |
Cat5, Cat5e |
| 10G support |
No |
| Networking standards |
IEEE 802.1D, IEEE 802.1ab, IEEE 802.1af, IEEE 802.1s, IEEE 802.1w, IEEE 802.3at, IEEE 802.3az, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x |
| Data transmission |
| Packet buffer memory |
0.525 MB |
| Jumbo frames |
9000 |
| Jumbo frames support |
Yes |
| Store-and-forward |
Yes |
| Forwarding rate |
35.7 Mpps |
| Switching capacity |
48 Gbit/s |
| MAC address table |
8000 entries |
| Security |
| Authentication type |
HWTACACS+, IEEE 802.1x, RADIUS |
| MAC address filtering |
Yes |
| Password protection |
Yes |
| SSH/SSL support |
Yes |
| Security algorithms |
802.1x RADIUS |
| Static port security |
Yes |
| IGMP snooping |
Yes |
| DHCP features |
DHCP client |
| Multicast features |
| Multicast support |
Yes |
| Design |
| Reset button |
Yes |
| Product colour |
Black |
| Stackable |
Yes |
| Rack mounting |
Yes |
| Performance |
| Noise level |
26 dB |
| Power |
| Power consumption (max) |
166.5 W |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| Power supply included |
Yes |
| Power source |
AC |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
130 W |
| Power over Ethernet (PoE) ports quantity |
12 |
| Power over Ethernet (PoE) |
Yes |
| Weight & dimensions |
| Weight |
2.48 kg |
| Height |
44 mm |
| Depth |
230 mm |
| Width |
330 mm |
| Packaging content |
| Manual |
Yes |
| User guide |
Yes |
| Quick start guide |
Yes |
| Cables included |
AC |
